Next time you fill your water bottle, watch closely and see if you can spot a bubble heart like these. When a jet falls into a pool, it pulls air in with it. The low pressure of the jet pulls bubbles inward, even as shear pulls the bubbles downward with the sinking liquid. If the bubbles are large and there’s enough momentum in the jet, the lower portion of the bubble will get pulled into a conical shape, while the upper portion remains a hemisphere. That forms one lobe of the heart. The other half requires a second bubble. But with a little patience and luck, you can form a complete heart. Happy Valentine’s Day! (Image credit: S. Tuley et al.)
Tag: science
Milano Cortina 2026: How Ski Skins Work
The 2026 Olympics include the debut of ski mountaineering (a.k.a. skimo), a sprint race heading both up and down the mountain on skis. During the uphill segment of the race, competitors use skins on their skis to help them climb; these skins then get ripped off (see below) before skiing back down.
As their name suggests, the first climbing skins used on skis were made from seal skin. By angling the seal fur, skiers could glide in the forward direction and resist sliding backwards. Modern skins may have animal or synthetic fibers, but they use the same physical mechanism. The angled hairs let skis slide forward easily, then grip and resist sliding backward. (Image credits: touring – H. Morkel, skins – Josefka, video – NBC Bay Area)
Fediverse Reactions
-
Milano Cortina 2026: Cortina Sliding Center
This year’s sliding events–bobsleigh, luge, and skeleton–will take place at the brand-new Cortina Sliding Center. Built on the site of a historic sliding track, this new venue came together in only the last couple of years. It features a state-of-the-art refrigeration system that pumps a mixture of water and ethylene glycol beneath the track surface to keep the ice properly chilled. Each section of the track is continuously monitored to optimize the flow rate, temperature, and pressure of the refrigerant to keep the track at maximum performance while minimizing environmental impact.
According to the designers, it’s the first competition track to use a glycol-based refrigeration system, which should be more sustainable than the ammonia-based systems used elsewhere. For a sense of what a run is like, check out this skeleton driver POV run from the facility’s shakedown competition last year. (Image credit: LMSteel; video credit: tuff sledding)
Fediverse Reactions
-
Milano Cortina 2026: Curling Stones
Ailsa Craig sits about 10 miles off the Scottish coast, a granite dome left behind by a volcanic event millions of years ago. This small, now-uninhabited crag is the birthplace for every Olympic curling stone. It’s where Kays of Scotland, which has made curling stones for the Olympics since the sport appeared in the first Winter Games in 1924, gets their granite.
Curling stones have to withstand both cold and collisions, something Ailsa’s microgranite excels at. Its elasticity keeps it from cracking, and Ailsa’s unique blue hone granite resists water absorption, so that freeze-thaw cycles don’t erode the surface. That waterproofing makes for the perfect running surface. It’s no wonder that the majority of curling stones in the world originate in Ailsa. (Image credit: A. Grant/AP; via AP)
Fediverse Reactions
-
Milano Cortina 2026: Ice’s Many Forms
Welcome to another Olympic year and another FYFD celebration of the fluid physics that enable these sports! All Winter Olympic sports are required, per the IOC, to take place on snow or ice–one of the strangest substances we know of.
Despite consisting of two simple elements–hydrogen and oxygen–water manages to find a shocking number of ways to configure itself into a solid. So far, scientists have described 21 different configurations for solid water ice. The latest one was created at room temperature and extreme pressures. (The apparatus used can reach pressures 20,000 times atmospheric pressure.)
This particular form of ice is metastable, meaning that it balances on a knife’s edge, existing briefly at conditions where other ice structures are energetically preferable. It’s likely that many such high-temperature, metastable ice forms exist. How many more do you suppose researchers will discover before the next Olympics? (Image credit: L. Borghese; research credit: Y. Lee et al.; via Gizmodo)
P.S. – Dig into past Olympics with posts from Beijing, PyeongChang, and Sochi.
Fediverse Reactions
-
“Cracked Earth”
Branching cracks wend through the slopes of Utah in this photograph by Matt Payne. It may seem strange to feature something so dry on a blog about fluid dynamics, but everything seen here depends as much on air and water as on soil, rock, and sand. How water intrudes into the porous landscape and the way it evaporates back out is critical to crack formation. (Image credit: M. Payne; via ILPOTY)
Gliding Like a Grasshopper
Many biorobots are built after flies and bees–insects that rely heavily on flapping flight. For small robots, this means carrying heavy batteries or remaining tethered in order to power their motors. Instead, researchers have turned to grasshoppers for a lesson in small-scale gliding.
Grasshoppers have two sets of wings. The forward set provide protection and camouflage, while the hindwings are used to fly. The team studied the corrugated, foldable hindwings of the American grasshopper, then 3D-printed model wing designs and attached them to gliders. They found that the corrugated wings performed well at low angles of attack, but that non-corrugated wings–which still shared the outline and camber of the insect’s wings–were more efficient gliders over a range of conditions.
The team hopes that their grasshopper-inspired gliders give insect-like biorobots more efficient flying options. (Image credit: Princeton/S. Khan/Fotobuddy; research credit: K. Lee et al.; via Physics World)
Fediverse Reactions
-
Instabilities in a Particle Flow
![Composite image of bed layers for 4 different particle density ratios. Text reads, "The wave amplitude and growth rate increase with particle density ratio but only if [the density of large particles is greater than the smaller particle density]."](https://fyfluiddynamics.com/wp-content/uploads/KHbed3.png)
Even though particles are not (strictly speaking) a fluid, they often behave like one. Here, researchers investigate what happens when two layers of particles–with different size and density–slide down an incline together. The video is tilted so that the flow instead appears from left to right.
When the larger, denser particles sit atop a layer of smaller, lighter particles, shear between the two layers causes a Kelvin-Helmholtz instability that runs in the direction of the flow. This creates a wavy interface that lets some small particles work upward while large particles shift downward.
At the same time, a slice across the flow shows that plumes of small particles are pushing up toward the surface, driven by a Rayleigh-Taylor instability. The researchers also look at what happens when the particles are fluidized by injecting a gas able to lift the particles. (Video and image credit: M. Ibrahim et al.; via GFM)
Watching Waves on the Nanoscale
It’s tough to simulate nonlinear wave dynamics, so scientists often test theories in wave flumes, where they can create more controlled waves than what we see in the wild. But conventional wave flumes are big–meters-long, complicated equipment–and can only test a small range of conditions. To reach more extreme nonlinear dynamics, researchers have turned to a chip-based approach. These 100-micron-long wave flumes carry a film of superfluid helium less than 7 nanometers thick. But despite that tiny size, the system can reach levels of nonlinearity five orders of magnitude greater than their full-sized counterparts. (Image and research credit: M. Reeves et al.; via Physics Today)
Fediverse Reactions
-
A Supernova in Motion
In 1604, astronomers first caught sight of Kepler’s Supernova Remnant, a massive explosion some 17,000 light-years away. Twenty-five years of observations from the Chandra X-ray Observatory went into making this timelapse, which shows the supernova remnant‘s material pushing into the surrounding gas and dust.
In its fastest regions, the supernova remnant is moving around 2% of the speed of light–some 22 million kilometers per hour. Slower parts of the remnant are moving at just 0.5% of light-speed. (Image credit: NASA/CXC/SAO/Pan-STARRS; via Gizmodo)
