  • Bursting Bubbles

    Bursting Bubbles

    When air bubbles rise through a liquid, they scavenge dust, viruses, microplastics, and other impurities as they go. Once at the surface, these contaminant-covered bubbles thin and burst, generating many tiny droplets that arc through the air above. You’re likely familiar with the sight and sensation from a glass of champagne or soda.

    Here, researchers have stacked two sets of sequential images to illustrate this complicated flowscape. Under the surface, a trio of photos are stacked to show bubbles rising and gathering at the surface. In the air, the researchers have stacked thirty sequential images, which together trace out the parabolic arcs of droplets sprayed by the bursting bubbles. (Image credit: J. Do and B. Wang)

    A research poster showing composite images of bubbles rising to a water-air interface and bursting, sending up a spray of microdroplets.
    Fediverse Reactions
  • Featured Video Play Icon

    Fire From Below

    A slight change in perspective can do wonders. In this video, the Slow Mo Guys look at a burning flame from below. They accomplish this by mounting a gas grill upside-down. This small change means that buoyancy can’t simply lift heat and exhaust gases away from the flame source. Instead, the flow pushes out and around the edges of the grill.

    The views are, as always, amazing. The billowing flames are mesmerizing–often closer to laminar than turbulent. And the added spectacle of cinnamon combusting in the later segments really does make for the kind of visuals you’d expect in a sci-fi movie. (Video and image credit: The Slow Mo Guys)

    Fediverse Reactions
  • Featured Video Play Icon

    Particles Separate When Flowing Downhill

    When particle-laden fluids like a mudslide flow downhill, even well-mixed particles can wind up separating. To explore how this works, researchers put glass spheres–of two different sizes but equal density–into silicone oil and let it flow down an incline. Their initially well-mixed oil soon turned red as the larger red particles overtook the smaller blue particles near the front. Looking at the flow from the side, the team observed a Brazil-nut-effect-like behavior where the larger particles move toward the top of the flow. That’s where the flow speed is fastest, and the particles are congregating there despite being denser than the oil carrying them! (Video and image credit: Y. Ba et al.)

  • Featured Video Play Icon

    Bioconvection

    Convection isn’t always driven by temperature. Here, researchers explore the convective patterns formed by Thiovulum bacteria. These bacteria are negatively buoyant, meaning they will sink if they aren’t swimming. They also have an asymmetric moment of inertia, so any flow moving past them tends to affect their swimming direction.

    When let loose in a Hele-Shaw cell with a oxygen levels that decrease with depth, the bacteria create complex convection-like patterns. They swim slowly upward in wide, slow plumes and sink in denser, narrow plumes. In other areas, they form large-scale rotating vortices. (Video and image credit: O. Kodio et al.)

    Fediverse Reactions
  • Turbulence and Bioluminescence

    Turbulence and Bioluminescence

    If you’ve ever seen crashing waves glowing blue, you’ve been treated to bioluminescence. Although many creatures can bioluminesce, tiny dinoflagellates–a type of marine phytoplankton–are one of the easiest to spot. These microscopic organisms create a flash of light in response to viscous stresses. Their response to flow-induced stresses is so robust that they can be used to visualize stress fields.

    In a new study, researchers explored how turbulence affects the dinoflagellate’s luminescence. They mathematically modeled the dinoflagellate as an elastic dumbbell that emitted light based on its extent and rate of deformation. Then they explored how this model dinoflagellate behaved in different types of turbulent flows. They found that the fluctuations and intermittency of turbulent flows both encouraged the radiant displays. (Image credit: T. McKinnon; research credit: P. Kumar and J. Picardo)

    Fediverse Reactions
  • Thunderstorms Make Trees Glow

    Thunderstorms Make Trees Glow

    Scientists have long hypothesized that the high electrical charge of thunderstorms could produce an opposite charge in the ground that would discharge from the forest canopy. But this phenomenon, known as a corona, had never been observed on actual trees. A new study, however, has observed this ghostly ultraviolet (UV) glow from the tips of sweetgum leaves and loblolly pine needles during thunderstorms.

    Catching these coronae in action required a new kind of UV detector that was ultra-sensitive to the particular band of UV-light emitted by coronas, hot fires, or mercury lamps. Since the latter two weren’t present during the team’s field observations, they were able to conclude that the light they detected came from coronae.

    The group observed that corona discharges were transient, jumping from leaf to leaf and branch to branch across the forest canopy. For any creature capable of detecting that glow by eye, it must be incredible to watch the treetops lit by their own ever-shifting auroras during every thunderstorm. (Image credit: W. Brune; research credit: P. McFarland et al.; via SciAm)

    A UV corona forms on tree leaves beneath a thunderstorm.
  • Featured Video Play Icon

    Making Sound Visible

    Sound is not something we can typically see, though there are ways to visualize it, including cymatics and special acoustic cameras. This video pursues a different tactic: using schlieren photography and stroboscopic lighting to show how sound waves reflect and deflect. It’s no easy feat, but one worth enjoying–especially when others have already done the hard part for you! (Video and image credit: All Things Physics; submitted by David J.)

  • Mixing Bubble Caps

    Mixing Bubble Caps

    When bubbles form atop the ocean or in our cups, they typically live short lives. Although the bubble can exchange fluid with the pool below, this only happens at the foot of the bubble cap. There, thinner patches form and, due to their buoyancy, rise up along the bubble’s surface. Over time, these lighter, thinner patches reduce the amount of fluid in the cap–causing the bubble to thin and eventually burst.

    A research poster showing how external turbulence affects the plumes that thin a bubble cap.

    Here, researchers show that thinning–visible in the dark blue plumes rising up the bubble cap–when there’s no turbulence in the surrounding air. But as turbulence outside the bubble increases, the thinner patches stretch and deform across the cap. In the image series, turbulence increases moving from top to bottom. (Image credit: T. Aurégan and L. Deike)

  • “Arctic Fox in Blizzard”

    “Arctic Fox in Blizzard”

    A blue arctic fox bears the wind and snow of a Norwegian blizzard in this image by photographer Klaus Hellmich. The wind is strong enough to move snowflakes several centimeters in the time the camera’s shutter is open. This leaves the image full of streaklines that reveal the paths taken by the wind and snow. This visualization technique is useful in the lab, too. (Image credit: K. Hellmich; via Colossal)

    "Arctic Fox in Blizzard" by Klaus Hellmich.
    Fediverse Reactions
  • Featured Video Play Icon

    Swirling Without Blades

    A ring of hydrogen bubbles rises, rotating clockwise, in this video of electrolysis. But there are no fan blades to cause this swirl, so why do the bubbles rotate? The answer is a Lorentz force induced by the electromagnetic set-up of the experiment. Watch to see how researchers manipulate the Lorentz force to affect the flow. (Video and image credit: Y. Cho et al.)
