  • Collective Motion: Waving Bees

    Collective Motion: Waving Bees

    Giant honeybees live in huge open nests. To protect themselves, they’ve developed a mesmerizing wave-like defense known as shimmering. When shimmering, the bees in a hive, beginning from a distinct spot, will flip over to expose their abdomens. Taken together, this creates large-scale patterns like those seen above.

    Scientists have connected the behavior to the presence of wasps that prey on the bees. It seems that shimmering helps to repel the wasps without putting individual bees in danger. If shimmering doesn’t ward off the wasps, the bees can also use their flight muscles to heat the area around the intruder to a wasp-lethal temperature – or, individuals bees can sacrifice themselves by stinging the wasp. (Image credit: Beekeeping International, source; research credit: G. Kastberger et al.; via Gizmodo)

    This post is part of our series on collective motion. Check out our previous posts about how crowds are like sand, the fluid properties of worms, and why a lack of randomness makes predicting group behaviors hard.

  • Collective Motion: Crowds

    Collective Motion: Crowds

    It’s sometimes taken for granted that, in groups, people can behave a lot like a fluid or a granular material. This allows scientists to adapt models developed for those materials to understand how crowds move. But in doing so, it’s always important to test just how far the comparison holds; in other words, just how much does a crowd of people behave like a fluid or granular material?

    That’s the purpose behind the experiment you see above, where a dense crowd of people shift in response to a “cylindrical intruder”. This is a classic experiment for something like a granular material, and there are clear similarities. Most of the crowd’s shifting comes only a short way from the intruder, and their passage leaves a small, empty wake that slowly fills back up.

    But other aspects of the experiment are very different from the granular equivalent. Instead of moving only when contact forces cause them to, the crowd shifts in anticipation of the intruder’s passage. They also use a more confined motion; crowd members primarily shift to the side to allow the intruder by, whereas grains tend to follow a more circular pattern of motion. Interestingly, if the intruder approaches from behind – and thus crowd members cannot anticipate them – the crowd’s motions will actually better match a granular material. (Image and research credit: A. Nicholas et al., source)

    All this week at FYFD we’re looking at collective motion. Check out our previous posts here and here.

  • Collective Motion: Worms

    Collective Motion: Worms

    Although most animals are more solid than fluid, what happens when you put many of them together can be strikingly fluidic. Above you see the black aquatic worm, Lumbriculus variegatus, which must keep moist to stay alive. An individual worm will die within an hour of being removed from the water, but, in a group, the worms can survive far longer. They do so, in part, by acting like a viscoelastic fluid, a material with both solid (elastic) and fluid (viscous) properties.

    In small groups, the worms squirm tightly together to minimize their collective surface area and prevent themselves from drying out. But in larger groups, the worm blobs begin sending out feelers, searching for more advantageous circumstances. In the top image, you can see this causes three of the blobs to ultimately merge into an even bigger one. The worm collective can also “liquify”, allowing the blob to change shape and tackle obstacles like flowing through a pipe. (Image and research credit: Y. Ozkan-Aydin et al.; via Science)

    This is the second post in our series on collective motion. Check out the first post here.

  • Collective Motion: Intro

    Collective Motion: Intro

    Herds, flocks, schools, and even crowds can behave in fluid-like ways. On Science Friday, Stanford professor Nicholas Ouellette explains some of the physics behind these similarities. Fluids are, after all, made up of a many, many individual particles – typically molecules – just the way a crowd of people or a school of fish contains many individuals. What makes the collective behaviors of groups harder to model than a fluid, however, is a lack of randomness. In something like water, all the molecules move randomly, which allows scientists to make certain simplifications in how we describe that motion.

    In animal group behaviors, on the other hand, the motion of an individual is not completely random. It instead seems to be governed by relatively simple rules based on the observations that an individual can make. Combine those rules across a large number of individuals and you can get what’s called emergent behavior – exactly the sort of large-scale patterns we see in swarms of insects, flocks of birds, and schools of fish. (Image credits: fish – N. Sharp; starlings – N. Fielding, source; battle – New Line Cinema; podcast credit: Science Friday; submitted by Michelle D.)

    This week on FYFD, we’ll explore the world of collective motion and how it overlaps with fluid dynamics.

  • Avoiding Ice

    Avoiding Ice

    Keeping ice from forming on a surface is a major engineering challenge. Typically, there’s no controlling certain factors – like the size and impact speed of droplets – so engineers try to tame ice by changing the surface. This can be through chemicals – as with deicing fluids used on aircraft – or by tuning the surface itself.

    One way to do this is by making the surface superhydrophobic – or extremely water repellent. These surfaces are rough on a nanoscale level, but they’re delicate, and once ice gets a grip on them, it’s even harder to remove. In a recent study, however, researchers used particles with both hydrophobic and hydrophilic – water-attracting – properties to create a superior ice-resistant surface. The combination of hydrophobic and hydrophilic aspects to the particles made supercooled droplets break up on contact with the surface. This made the drops smaller and decreased their contact time, making it harder for them to stick and freeze. (Image credit: Pixabay; research credit: M. Schwarzer et al.; via Chembites; submitted by Kam-Yung Soh)

  • Simulating Solar Flares

    Simulating Solar Flares

    Few topics in fluid dynamics are more mathematically complicated than magnetohydrodynamics – the marriage between electromagnetism and fluids. That mathematical complexity, along with the vast range of scales necessary to describe physical systems like our sun, means that, until now, researchers had to simplify their assumptions when simulating solar physics. But now, for the first time, a group has built a comprehensive, three-dimensional simulation capable of generating realistic solar flares. This is what you see above.

    Solar flares occur when a tangle of magnetic loops near the sun’s surface break and reconnect, releasing enormous magnetic energy and spewing a fountain of ionized plasma into the corona. They’re a danger particularly to satellites in orbit, so being able to simulate these events realistically is a major advance toward understanding the physics of space weather. (Image and video credit: NCAR & UCAR Science; research credit: M. Cheung et al.; via Bad Astronomy; submitted by Kam-Yung Soh)

  • Liquid Antispiral

    Liquid Antispiral

    Spiral formations are common in nature, from galaxies to chemical reactions. But most examples in nature rotate such that their arms trail the direction of rotation. Viewed side-on, this makes the arms appear to spiral outward from the the center. The opposite – an antispiral, where the arms appear to be drawn in toward the center – also exists, but there are far fewer examples. Which is why it’s notable that physicists have described a new one, seen above.

    You’re watching silicone oil draining through a plate with an array of holes in it. There’s a reservoir of oil on top supplying a constant flow rate. The patterns that form in this system vary widely – they can form between one and six arms – but the results are always antispirals. The driving mechanism seems to be the periodic nature of the discharge from individual holes, which is caused by a Rayleigh-Taylor instability. Hopefully systems like this can shed some light on why spirals are often preferred over antispirals. (Image and research credit: H. Yoshikawa et al.; via APS Physics)

  • Featured Video Play Icon

    Worthington and His Jets

    If you’ve been around fluid mechanics for very long, you’ve probably noticed that we like to name things after people. (Mostly dead, white guys, but that’s another subject.) Whenever someone describes or explains a new phenomenon, it tends to get their name attached to it. Some of the common names in fluid dynamics – Reynolds, Rayleigh, Kelvin, Taylor, von Karman, Prandtl – read like a who’s-who of nineteenth and twentieth century physics. This video gives some historical insight into a couple of those figures – particularly Arthur Worthington, who is known for his contributions to the understanding of splashes. Be sure to check out some of his awesome illustrations and photos. Can you imagine being able to piece together splash physics like that without high-speed video?! (Video credit: Objectivity; submitted by Kam-Yung Soh)

  • Featured Video Play Icon

    The Polar Vortex

    Every year or two, the Northern Hemisphere gets treated to a bout of intensely cold temperatures thanks to the polar vortex. What you may not realize, though, is that it’s not the polar vortex that causes this cold weather – it’s the vortex breaking down. As Simon Clark explains in this video, the polar vortices (one at each pole) are intense and powerful regions of circulation in the stratosphere, or mid-atmosphere. They’re largely responsible for keeping cold air trapped in the Arctic and Antarctic. But occasionally, this region of the atmosphere will suddenly get warmer – to the tune of increasing by 80 degrees Celsius in less than a week! When this happens, a polar vortex will deform and potentially even split into smaller vortices, as seen below. When this happens, the vortex loses its hold on the cold air near the surface, allowing Arctic air to sneak as far south as Texas. After a couple of weeks of affecting our weather, the polar vortex will typically reform and we’ll return to normal. In the meantime, stay warm! (Video and image credit: S. Clark; submitted by Nikhilesh T.)

  • Featured Video Play Icon

    Dripping Down the Rivulet

    If you’ve ever watched water running down the side of the street, you’ve probably noticed that it doesn’t flow smoothly. Instead, you’ll see waves, rivulets, and disturbances that form. That’s because the simple action of flowing down an incline is unstable. Water and other viscous liquids can’t flow downhill smoothly. Any disturbances – an uneven surface, the rumble of passing cars, a pebble in the way – will create a disruption that grows, often until the entire flow is affected. This video shows some of the complex and beautiful patterns you get then. (Video and image credit: G. Lerisson et al.)
